Handheld Marking Machine for Fire Extinguisher have become an integral part of the fire extinguisher industry. More and more fire extinguisher industry practitioners are realizing the importance of product identification and traceability. Efficient and convenient handheld marking machines are gradually replacing the cumbersome and easy to imitate traditional marking, inkjet printers, rolling molds and other methods. The handheld marking machines for fire extinguisher can modify the marked text and pattern at any time. The performance is extremely consistent and not easy to imitate.
As one of the professional China Handheld Marking Machine for Fire Extinguisher manufacturers and China Handheld Marking Machine for Fire Extinguisher suppliers, we are strong strength and complete management.
Handheld marking machines for fire extinguisher have become an integral part of the fire extinguisher industry. More and more fire extinguisher industry practitioners are realizing the importance of product identification and traceability. Efficient and convenient handheld marking machines are gradually replacing the cumbersome and easy to imitate traditional marking, inkjet printers, rolling molds and other methods. The handheld marking machines for fire extinguisher can modify the marked text and pattern at any time. The performance is extremely consistent and not easy to imitate
LYQD-SC1503A: The lightest and high-accuracy pneumatic handheld marking machine
LYQD-SC1503A, machine head weighting only 2.6KG, with customized fittings bracket to fit different marking work piece. With Windows style human-computer interaction operating system, LYQD-SC1503A make the marking process easy and convenient.
LYQD-SC1503A could give your product a permanent and durable marking performance. LYQD-SC1503A equipping high precision stepping motor and single guide rail, makes little working noise and high-performance. With stainless steel frame, 22cm*18cm*8cm machine head size and 80mm*30mm - 150mm*30mm marking size, LYQD-1503A could fit most marking pieces and terrible, narrow working environment, especially for the car VIN code.
The operating system support text, matrix, vector graph with the serial, VIN, PIN, VCode, date time, etc coder type to fit different kinds of workers.
Model | LYQD-SC1503A |
Marking type | Pneumatic handheld |
Air pressure | 0.2-0.6Mpa |
Dimensions | 22cm*18cm*8cm |
Weight | 2.6KG |
Power supplier | 220V, 50Hz, two-phase power |
Marking area | 80mm*30mm, 120mm*30mm, 150mm*30mm |
Marking depth | 0.01-0.2mm |
Stepping motor | Digital drive Yamayama, Japan |
Guide rail | Hiwin, Taiwan, China |
Needle | Tungsten steel, Japan |
Fittings | Standard and customized |
Electromagnetic marking Assembly | Germany |
1. Customized and OEM orders are supported.
2. All the OEM services are free, customer only need to provide us with your logo drawing, function requirements, colors, etc.
3. No MOQ required.
4. Sincerely looking for distributors all over the world.
